| Colour display - 262144 colours
- 7" (17.5cm) screen size
- 800 by 480 pixel resolution
- 1200 cd brightness
Hardware - Dual core ARM Cortex-A9 processor running on 1GHz
- 16Gb storage memory
- 8 push buttons and 4 rotary switches
- 56-channel uBlox GPS receiver
- FLARM transmitter and receiver
- Engine noise level sensor
- Pressure altitude sensor
Input and output - Integrated SD card reader
- Serial RS232 interface
- RS485 bus interface
- FLARM interface
- USB interface
Optional Accessories - Rear seat device LX8080D,LX8000D, LX9000D or LX9070D
- Remote stick
- High precision compass
- Voice module (integrated in V5/V9 as standard part)
- Additional external V5 indicator
- External FLARM display
- ADSB receiver (see other aircrafts as flarm objects on map)
Size and weight
Power and battery - Current drain display unit 380mA at 12V without integrated Flarm at 50% LCD brightness (600nits - still readable under sunlight)
- Current drain display unit 480mA at 12V without integrated Flarm at 100% LCD brightness (1200nits)
- Without Flarm option is additional 20mA less
- Current drain vario unit 120mA at 12V
- Smart power management
- Automatic backlight regulation
V8 VARIO Dual ARM Cortex-M4 processor on 160MHz Extremely bright 2.5” color display with 320x240 pixels Digital temperature compensated pressure sensors for altitude and airspeed Inertial platform 3 axis digital +-6g accelerometer, 4 gyroscopes (for inertial vario, AHRS and wind calculation) No mechanical parts allow extremely fast response time of needle Additional Flarm radar screen and artificial horizon 3 push buttons for setting adjustments ALS (ambient light sensor) External SD card for configuration, flarmnet and FW update V9 Vario - ARM Cortex-M4 processor running on 160MHz
- Mechanical needle driven by stepper motor
- QVGA (320*240pixels) sulight readable display
- Digital temperature compensated pressure sensors for altitude and airspeed
- inertial platform (for inertial vario, AHRS and wind calculation)
- 3 axis accelerometer
- 3 axis gyros
- AHRS (optional with FW update)
- Smooth 16bit audio output
- Audio equalizer
- integrated synthesized speech output
- Audible thermal assistant
V80 Vario Dual ARM Cortex-M4 processor on 160MHz Extremely bright 3.5” (9 cm) color display with 320x240 pixels Digital temperature compensated pressure sensors for altitude and airspeed Inertial platform 3 axis digital +-6g accelerometer, 4 gyroscopes (for inertial vario, AHRS and wind calculation) No mechanical parts allow extremely fast response time of needle Additional Flarm radar screen and artificial horizon 3 push buttons for setting adjustments ALS (ambient light sensor) External SD card for configuration, flarmnet and FW update V9/V8/V80 Input and output RS485 bus Speed command and Vario priority input additional 4 digital inputs Smooth audio output Speech output (voice module) Flarm warning indication Optional AHRS (V8 and V80 |
